General Information

●   The design, manufacturing and quality control of the JWS pumps comply with the GB/T5656 "Centrifugal  Pump  Technical Requirements, Class II"standard,and  its efficiency index meets the GB/T19762 "Clear  Water   Centrifugal  Pump  Energy Efficiency   Limit   and  Energy   Conservation   Evaluation   Value"  or equivalent ISO standards.

Applications

lClean water  or  other   liquids   with   similar   physical   and   chemical   properties  to    clean    water.
lIndustrial   wastewater, seawater  or  muddy  water  with   a  small  amount  of  particles.
lWater  supply   and  drainage  systems
lCooling  water  circulation   systems
lUrban  tap  water
lHeat   network   circulating   water
lHVAC (Air   conditioning   system circulating  water)
lFarmland irrigation and  drainage
lRegional water transfer & water conservancy
lThermal power  generation
lMining  & Steel
lOther Industrial
lPetrochemical

Working Condition

●  Inlet  diameter:DN125~DN900

●  Outlet  diameter:DN80~DN900

●  Medium  temperature:

-20~+80℃ (Standard materila and structure);

≤150℃ with cast steel materila and cooling structures for bearings and seal

●   Pressure   0.6Mpa, 1.0Mpa,1.6Mpa,2.5Mpa,2.8Mpa

● The design pressure is related to the material of the pump housing.The pressure of inlet and outlet flanges on the pump are related to the design pressure and material of the pump body.

● Allowable  inlet  pressure: design  pressure  at  rated  head

● Hydro test pressure: 1.5 times the design pressure (Duration 10mins or 30mins as per customer’s rerquests)
